Description
Our custom Curved Perforated Aluminum Panels merge advanced metal fabrication with architectural design, offering unparalleled flexibility for modern building envelopes and interior spaces. Engineered for both aesthetic impact and functional performance, these panels are the ideal solution for creating dynamic, lightweight, and sustainable structures.
| Attribute Category | Specifications & Options |
|---|---|
| Material | Alloy 1100 (Pure), 3003, 5005, 6061 (Structural) |
| Temper | H14, H24, H32, O (Annealed for severe bending) |
| Thickness | 1.0mm – 4.0mm (Standard), up to 6.0mm (Custom) |
| Panel Dimensions | Custom, based on curvature and project requirements |
| Curvature Types | Single Curved (Cylindrical), Double Curved (Compound), Custom 3D Shapes |
| Perforation Patterns | Round, Square, Slot, Decorative, Custom Logo |
| Hole Diameter / Slot Size | 1.0mm – 20.0mm (Customizable) |
| Open Area Ratio | 5% – 70% (Standard), custom ratios available |
| Surface Finishes | PVDF Coating (Standard), Anodized (Clear, Bronze, Black), Powder Coating (Any RAL Color), Brushed, Mirror |
| Core Benefits | Ventilation, Sun Shading, Acoustic Absorption, Aesthetic Appeal, Lightweight |
| Fire Performance | A2-s1, d0 (Non-combustible) |
| Standards | ASTM B209, EN 1396, AAMA 2605 (for PVDF coatings) |
